INSTALLATION
6
READ THIS CAREFULLY BEFORE STARTING THE INSTALLATION
Unpack the unit. Inspect all components for completeness and
condition. Ensure that all packing materials have been removed
from the unit.
Read all instructions in this manual carefully before starting
installation of this fryer. READ AND UNDERSTAND ALL
LABELS AND DIAGRAMS ATTACHED TO THE DISPENSER.
Carefully account for all components and accessories before
discarding packing materials:
1 ea. LID ASSEMBLY
1 ea. DRIP TRAY ASSEMBLY
1 ea. HOPPER MOUNTING TRAY
2 ea. HOPPER ASSEMBLY (9454) or
3 ea. HOPPER ASSEMBLY (9456)
1 ea. PRODUCT LABEL SHEET
1 ea. LITERATURE PACKAGE
Store these components in a convenient place for later use:
LEVELING THE UNIT
Set dispenser in its operating location. Level the dispenser.
A spirit level should be placed on the top of the unit, at the edge,
as a guide when making level adjustments.
PLUMBER’S INSTALLATION INSTRUCTIONS
Brewer must be connected to a POTABLE WATER, COLD
WATER line. Flush water line before connecting to Brewer.
DO NOT use a saddle valve with a self-piercing tap for the water
line connection. Such a tap can become restricted by waterline
debris. For systems that must use a saddle tap, shut off the main
water supply and drill a 3/16” (minimum) tap for the saddle
connection, in order to insure an ample water supply. Remember
to flush the line prior to installing the saddle.
The brewer must be installed on a water line with average
pressure between 20 PSI and 90 PSI. If your water pressure
exceeds 90 PSI at anytime, a pressure regulator must be
installed in the water supply line to limit the pressure to not more
than 90 PSI in order to avoid damage to lines and solenoid.
A water shut-off valve should be installed on the incoming water
line in a convenient location (Use a low restriction type valve,
such as a 1/4-turn ball valve, to avoid loss of water flow thru the
valve.
A water line strainer (not provided; ¼" flare "y" strainer available
separately as p/n SA9052) must be installed in the supply line,
between the shutoff valve and inlet fitting. Note FLOW arrow
marking on strainer body.
IMPORTANT:
To enable the installer to make
a quality installation and to
minimize installation time, the
following suggestions and tests
should be done before the
actual unit installation is started:
CAUTION:
ELECTRICAL
DAMAGE
DO NOT plug in or energize this
appliance until all Installation
Instructions are read and
followed. Damage to the
Brewer will occur if these
instructions are not followed.
IMPORTANT: This equipment
must be installed to comply with
applicable federal, state and
local plumbing codes and
ordinances.
NOTE: Water supply inlet line
must meet certain minimum
criteria to insure successful
operation of the brewer.
Bloomfield recommends 1/4"
copper tubing for installation of
less than 12 feet and 3/8" for
more than 12 feet from a 1/2"
water supply line.
