Upgrade
Innovation to Master Innovation
User manual
Page 8
clearaudio electronic GmbH 2014
5.)
Take out the delivered drive bearing for the
Master Innovation
.
Please remove carefully any protective security tape from the bearing.
Now you can put the new bearing into the chassis (see pic. 6) and arm the bearing with the
delivered screw on the lower side of the turntable.
6.)
Now please exchange the pulley of the
Innovation
turntable with the delivered pulley.
Pic. 6: Set – up of the drive bearing
Pic. 7: Exchange of the pulleys.
Pulley
Innovation
