30 MYTHOS
Channel Mode DMX
Value
Function
Standard Vector
FUNCTION
0 - 11 Unused range
12 - 24 Fast Pan / Tilt speed (default)
25 - 37 Normal Pan / Tilt speed
38 - 50 Conventional Dimmer curve
51 - 62 Linear Dimmer curve (default)
63 - 75 CMY Full Range (default)
76 - 87 CMY Limited range
88 - 101 CMY shortcut ON (default)
102 - 114 CMY shortcut OFF
115 - 255 Unused range
The functions are activated/selected passing through the unused levels range
and staying in the necessary range for 5 seconds.
RESET
0 - 25 Unused range
26 - 76
Zoom Reset
Zoom Reset sequence is activated passing through the unused levels range
and staying in this range for 5 seconds
77 - 127
Pan / Tilt Reset
Pan/Tilt Reset sequence passing through the unused levels range and staying
in this range for 5 seconds.
128 - 255
Complete Reset
All-effects Reset sequence passing through the unused levels range and
staying in this range for 5 seconds.
LAMP CONTROL
0 - 25 Unused range
26 - 100
Lamp OFF
Lamp switch-off passing through the unused levels range and staying in this
range for 5 seconds.
101 - 255
Lamp ON
Lamp switch-on passing through the unused levels range and staying in this
range for 5 seconds.
MACRO EFFECTS
0 – 7 Macro OFF
8 – 11 Standby
12 – 15 Standby black
16 – 45 Zoom IN Faded
46 – 75 Zoom OUT Faded
76 – 105 Zoom IN OUT
106 – 135 Standby Black 1
136 – 165 Zoom IN Faded Random
166 – 195 Zoom OUT Faded Random
196 – 225 Zoom IN OUT Random
226 - 255 Standby Black 2
PAN-TILT TIME
Pan - Fine Pan - Tilt - Fine Tilt
COLOUR TIME
Cyan - Magenta – Yellow
BEAM TIME
Dimmer - Frost - Prism – Focus - Zoom
GOBO TIME
Static Gobo – Rotating Gobo
