11 MYTHOS
OPTIONS MENU
LAMP DMX
It lets you enable (ON) the lamp remote control channel. Select OFF to turn off or disable this option.
SAFETY BLACK OUT
This allows the Dimmer's automatic lock option to be activated (ON) after 3 seconds with no incoming DMX signal. Select
OFF to turn off or disable this option.
PAN / TILT
Invert Pan
It lets you enable (ON) Pan reverse movement. Select OFF to turn off or disable this option.
Invert Tilt
It lets you enable (ON) Tilt reverse movement. Select OFF to turn off or disable this option.
Swap Pan-Tilt
It lets you enable (ON) Pan and Tilt channel inversion (and simultaneously Pan fine and Tilt fine). Select OFF to turn off or
disable this option.
Encoder Pan-Tilt
It lets you enable (ON) or disable (OFF) Pan and Tilt Encoder operations.
You can quickly disable the Pan and Tilt Encoder by simultaneously pressing the UP (
Ĺ) and DOWN(Ļ) keys in the
''Main Menu''.
P/T Homing Mode
It lets you set the initial Pan and Tilt Reset mode.
•
Standard: Pan & Tilt are simultaneously reset.
•
Sequenced: Tilt is reset first followed by Pan.
Pan Home Def Pos
It lets you assign the Pan channel “home” position at the end of Reset (without a DMX input signal), selecting one from
the 4 available positions:
• 0 degree
•
90 degrees
•
180 degrees
•
270 degrees (default)
Tilt Home Def Pos
It lets you assign the Tilt channel “home” position at the end of Reset (without a DMX input signal), selecting one from the
7 available positions:
•
0%
•
12.5%
•
25%
• 50% (default)
• 75%
•
87.5%
•
100%
