LAMP DMX
Used for enabling lamp remote control channel.
1) Press
F - the current settings appear on the display (On or Off).
2) Use the UP B and DOWN C keys to enable (On) or disable (Off)
the lamp remote control channel.
3) Press F to confirm the selection or LEFT D to keep current settings.
PAN / TILT
Invert pan
Used for reversing Pan movement.
1) Press
F - the current settings appear on the display (On or Off).
2) Use the UP B and DOWN C keys to enable (On) or disable (Off)
PAN inversion.
3) Press F to confirm the selection or LEFT D to keep current settings.
Invert tilt
Used for reversing tilt movement.
1) Press
F - the current settings appear on the display (On or Off).
2) Use the UP B and DOWN C keys to enable (On) or disable (Off)
Tilt inversion.
3) Press F to confirm the selection or LEFT D to keep current settings.
Swap Pan-Tilt
Used for swapping Pan and Tilt channels (as well as Pan fine and Tilt fine).
1) Press
F - the current settings appear on the display (On or Off).
2) Use the UP B and DOWN C keys to enable (On) or disable (Off)
Pan and Tilt channel swap.
3) Press F to confirm the selection or LEFT D to keep current settings.
Encoder Pan-Tilt
Used for enabling the Pan / Tilt encoders.
1) Press
F - the current settings appear on the display (On or Off).
2) Use the UP B and DOWN C keys to enable (On) or disable (Off)
Pan / Tilt encoders.
3) Press F to confirm the selection or LEFT D to keep current settings.
COLOR
Color mixing
Used for reversing the CMY color mixing system.
1) Press
F - the current settings appear on the display (On or Off).
2) Use the UP B and DOWN C keys select one of the following settings:
RGB color mixing mode
CMY color mixing mode
3) Press F to confirm the selection or LEFT D to keep current settings.
Color mixing curve
It lets you select the “Color mixing curve” from the two available.
1) Press
F the current setting appears on the display.
2) Use the UP B and DOWN C keys to select one of the following settings:
Curve 1
Curve 2
3) Press F to confirm the selection or LEFT D to keep the current setting.
Fixed wheel short-cut
Used for optimizing color change time so that the disc turns in the direc-
tion that requires shorter movement.
1) Press
F – the current settings appear on the display (On or Off).
2) Use the UP B and DOWN C keys to enable (On) or disable (Off)
color change optimization.
3) Press F to confirm the selection, or LEFT D to keep current settings.
Swap
Pan-Tilt
On
Off
Encoder
Pan-Tilt
On
Off
Lamp Dmx
Pan / Tilt
Option
On
Off
Invert
Pan
On
Off
Invert
Tilt
On
Off
OPTIONS MENU
Color
Color
Mixing
Rgb
Cmy
Fixwheel
Shortcut
On
Off
Color
Mixing curve
Curve 1
Curve 2
