Clay Paky ALPHA WASH 700 (C61350) User Manual
Page 19
19
ALPHA WASH 700
Extraction of the effect modules
- Fig. 18
IMPORTANT: Grasp the modules using the support structure and not the details which could get damaged.
Insertion of the effect modules:
Repeat the operations indicated in Fig. 16 - 17 - 18 and 19 in reverse order.
5
3
4
Upper Side
Upper Side
Lower Side
18
099100_AlphaWash700_Rv2_EN_ 23/02/11 17.06 Pagina 19
