8 ALPHA BEAM 1500
DMX ADDRESS
NOTE: without the DMX signal the Address (XXX) flashing
Allows you to select the DMX ADDRESS
1) Press
- the current DMX Adress appear on the display.
2) Use the UP , DOWN , RIGHT keys to plan the DMX
Address.
3) Press to confirm the selection or LEFT to keep current settings.
CHANNEL MODE
Allows you to select a channel arrangement from the two available.
1) Press
- the current settings appear on the display (Standard or
Vector).
2) Use the UP and DOWN keys to select one of the following
settings:
- Standard
- Vector
3) Press to confirm the selection or LEFT to keep current settings.
FIXTURE ID
Allows you to select the FIXTURE ID
1) Press
- the current Fixture ID appear on the diplay.
2) Use the UP , DOWN , RIGHT keys to plan the Fixture ID.
3) Press to confirm the selection or LEFT to keep current settings.
ETHERNET INTERFACE
It lets you set the Ethernet settings to be attributed to the projector.
1) Premere
.
2) Use the UP and DOWN keys to select the “Ethernet Interface”
options to set:
Control Protocol
It lets you select the “Control Protocol” Art-net to assign according to the
control unit used:
1) Press
the current setting appears on the display.
2) Use the UP and DOWN keys to select one of the following settings:
- Disabled
- Art-net on IP 2
- Art-net on IP 10
3) Press to confirm the selection or LEFT to keep the current setting.
Repeat on DMX
It lets you enable the transmission of the Ethernet protocol by DMX signal
to all the connected projectors.
1) Press
the current setting appears on the display.
2) Use the UP and DOWN keys to select one of the following settings:
- Disabled: DMX transmission disabled.
- Enabled on primary: DMX transmission enabled.
3) Press to confirm the selection or LEFT to keep the current setting.
Universe
It lets you assign the “Universe” number to be assigned to a series of
projectors.
1) Press
– the current Universe address appears on the display.
2) Use the UP , DOWN , RIGHT keys to set the Universe address.
3) Press to confirm the selection or LEFT to keep the current setting.
SET UP MENU
Set Up
Dmx
Address
Channel
Mode
Fixture Id
Address xxx
Standard
Vector
Value xxx
NOTE: On grey the default options
Ethernet
Interface
Control
Protocol
Repeat on
DMX
Universe
