12 ALPHA BEAM 1500
BOARD DIAGNOSTIC
Used for displaying the status error of each board installed in the projector:
0: PT-3f (Pan / Tilt board)
1: 8-Ch (8 channel board)
2: 8-Ch (8 channel board)
DMX MONITOR
Used for displaying the projector DMX channel level in bit (Val) and in
percentage (Perc).
FANS MONITOR
Used for displaying the speed of each fan installed in the projector:
Pwr.Sup (Power supply Fan)
Ball. IN (Ballast IN Fan)
Ball. Out (Ballast OUT Fan)
Eff.IN (Effects IN Fan)
Eff.OUT (Effects OUT Fan)
Iris (Iris Fan)
Lamp (Lamp Fan)
NETWORK PARAMS
Allows the "Network" parameters of the projector to be displayed or:
IP address: Internet Protocol address (two projectors must not have the
same IP address)
IP mask:
Mac address: Media Access Control: the projector’s Ethernet Address.
LAMP
Used for turning lamp on and off from the projector control panel.
1) Press
- the current settings appear on the display (On or Off).
2) Use the UP and DOWN keys to turn the lamp on (On) or off (Off)
3) Press to confirm the selection or LEFT to keep current settings
and return to the top level.
RESET
Used for resetting the projector.
1) Press
to reset the projectors, a confirmation message (Are you sure ?)
appears on the display.
2) Select YES to starting reset the fixture or NO to keep the current setting
and return to the top menu level.
CHANNEL
Used for setting channel levels from the projector control panel.
1) Press
- the first channel appears on the display.
2) Use the UP and DOWN keys to select the required channel:
3) Press and use the UP and DOWN keys to select the
required DMX level (value between 0 and 255).
4) Press LEFT to return to the top menu level.
Channel
MANUAL CONTROL
Lamp
Manual
Control
On
Off
No
Yes
Reset
Fans
Monitor
Network
params
Fan Speed (RPM)
Pwr.Sup XXXX
Ball.In. XXXX
Ball.Out XXXX
Eff.In XXXX
Eff.Out XXXX
Iris XXXX
Lamp XXXX
Board
Diagnost.
Dmx
Monitor
Board Status Err%
0:PT-3f Good 0.00
1:8-Ch Good 0.00
2:8-Ch Good 0.00
