10. Find total number of Wires:
 2.
TTl WIRes
11. Find Conduit Fill Percent:

fIll 24.3
% ConD
12. Find actual Fill Area:

fIll 0.3710
TTl WIRe aRea
13. Find Remaining Area:

ReM 0.1021
WIRe aRea
Note: If a Wire Size has been calculated or stored, and the Wire Type/
quantity is not defined, the calculator will assume 2 THHN wires for
1Ø and 3 THHN wires for 3Ø when calculating Conduit Size.
finding Conduit sizes for Multiple Conductors —
Same Wire type and Size
Find the minimum IMC Conduit Size for eleven #6 THHN Copper
wires.
KeysTRoKe DIsPlay
 
0.
1. Set to Copper (if necessary):
  (Cu/Al)
Cu
0.
2. Enter Conduit Type:
  
(Cond Type) IMC none
ConD
3. Enter Wire Size:
  * aWG 6 Cu
WIRe sIZe
4. Enter # THHN:
   Thhn 11.
WIRes
(cont’d)
KeysTRoKe DIsPlay
