34 — ElectriCalc LT
Finding Voltage Drop Wire Size
A 20-amp single-phase 208-volt load
will be located 175 feet away from the
source. Assuming a 3% allowable volt-
age drop, what is the size of 75°C con-
ductor required for this branch circuit?
Steps Keystrokes Display
Reset calculator [Set] [x] 0.
Set to 75°C [Set] 7 3Ø 75 Cu 0.
Set to single ph. [Set] 1 1 PH
Enter amps 20 [Amps] 20. AMPS
Enter volts 208 [Volts] 208. VOLT
Enter distance 175 [Length] 175. FEET
Enter allow. VD% 3 [VD%] 3 DROP V %
Find wire size [WireSz] 8 CU
AWG WIRE SIZE
Find actual
voltage drop
[VD%] 5.4 DROP V
Find % v.drop [VD%] 2.6 DROP V %
