24 — ElectriCalc LT

Ampacity Wire Sizing

The required wire size of a service con-
ductor can be determined based on the
specified electrical requirements and
the [WireSz] key. The wire size is auto-
matically recalculated whenever the
wire insulation (temperature) ratings or
wire material (copper or aluminum)
types are revised. Wire sizing is based
on the requirements defined in NEC
Tables 310-16 and 310-17.

Wire Sizing Based
on Insulation Rating

Wiring is being installed in a 240 volt,
single-phase system rated at 30 kVA.
What is the wire size needed if you use
60°C copper wire?

Steps Keystrokes Display
Clear calculator

[On/C] [On/C]

Set to 1-phase

[Set] 1

1 PH

Set to 60

Û&

[Set] 6

1Ø 60 Cu 1 PH

Enter kVA

30 [kilo-] [VA]

30. KVA

Enter volts

240 [Volts]

240. VOLT

Find amps

[Amps]

125. AMPS

Find CU wire size [WireSz]

0 CU

AWG WIRE SIZE
