10 — ElectriCalc LT
♦
Second Press
If a wire length has been entered, the
second press displays the smaller of the
two wire sizes. If not solving for voltage
drop wire size, then displays the maxi-
mum ampacity.
♦
Third Press
If a wire length has been entered, dis-
plays the minimum wire ampacity rating.
[Set] [WireSz] — 125% Ampacity
Operates same as [WireSz], except that
a factor of 125% is applied to the am-
perage.
[ParSz] — Parallel Size
Used to find the size of parallel con-
ductors using amperage and an entered
quantity of wires. Parallel wire size
computations smaller than 1/0 are dis-
played as “nonE” as the NEC does not
allow parallel wire runs smaller than 1/0.
NOTE: No adjustments are made for
deration
♦
.First Press
When preceded by a number, calcu-
lates the applicable wire size for that
quantity of wires in parallel.
Displays: PAR WIRE SIZE.
♦
Second Press
