Linear Dimensions
Below are some examples of how linear
dimensions are entered:
Dimensions Keystrokes
17.5 Meters 17.5 [m]
5 Feet 5 [Feet]
1/2 Inch 1 [/] 2
5 Feet 1 Inch 5 [Feet] 1 [Inch]
5 Feet 1-1/2 Inch 5 [Feet] 1 [Inch] 1 [/] 2
10 Yards 10 [Yds]
205 Millimeters 205 [mm]
Square and Cubic Dimensions
Square and cubic dimensions are entered in
the following order:
(1) Numerical Value;
(2) Convention — Square or Cubic;
(3) Units — Meters, Yards, Feet, Inches.
Below are some examples of how square and
cubic dimensions are entered:
Dimension Keystrokes
33 square millimeters 33 [Sq] [mm]
5 cubic yards
5 [Cu] [Yds]
130 square feet 130 [Sq] [Feet]
123 cubic meters 123 [Cu] [m]
