rAPid FlOW inSTAllATiOn
rapid Flow exhaust # 81044
2. Place all of the supplied Hangers into their
appropriate locations as shown in the above
diagram. There is a hanger on the Catalytic
converter that will be reused .
3. In order to fit the new Down Pipe into the engine
bay, the firewall seam might need to be bent
or trimmed in order to provide the necessary
clearance. If you use either an adjustable wrench or
vise grips to grip the seam lip as far as possible and
bend the lip out of the way. Make sure your Down
Pipe is not rubbing on anything that will cause
noise or friction on any part.
4. Install the Down Pipe by sliding it up from
underneath the truck. You will use the stock band
clamp to secure the Down Pipe to the turbo. Secure
the Down Pipe by tightening the stock band clamp
with a 7/16” deep socket.
5. Install the Second Piece Down Pipe to the Down
Pipe using one of the supplied clamps. At this point
secure the connection, but don’t tighten down the
clamp until the entire exhaust is installed.
Hang the Hangers
Fire Wall Adjustment Area
7/16”
Stock Band Clamp
Down Pipe
Install Down Pipe
Install Second Piece Down Pipe
