Bully Dog 153002 Super Aggressive Shift Enhancer - Manual (Page 7)

6
Changing Vavles
VALVE BODY ASSEMBLY: When bolting the
valve body back up to the transmission, torque all
the bolts to 8 ft/lbs.
6.See the Separator Plate Drilling diagram to find where to drill out the two holes, then use the 3.5 mm drill bit
that is included with the kit to drill out those two holes.
7. Finally reassemble the valve body and then install back onto the transmission. Torque the bolts that connect
the valve body to the transmission to 8 ft/lbs.
SEPARATOR PLATE DRILLING DIAGRAM
