HARNESS DESCRIPTION
Harness Description
REMOvING FUSES FOR ’01-’02 GM DURAMAx vEHICLES
IMPORTANT: Skip the steps on this page if your vehicle is not an ’01-’02 GM 6.6L Duramax .
WARNING: Failure to remove the fuses while downloading the programs into the computer may result in computer
hardware failure.
•’01-’02 Duramax : Refer to Figure 1 to see the
fuses that must be removed prior to downloader
installation.
• SEO ING
• RD01
• RAP2
Note: Use your fuse puller included with your vehicle or a pair of needle nose pliers to pull the fuses.
‘0-’02 Fuse Box
IMPORTANT: This fuse box is located
inside the cab on the driver’s side
