11
NOTE:
Each click of adjustment changes bullet strike at a shooting distance of 100 yards
by the amount indicated on the windage and elevation knobs. To calculate the click
value at distances other than 100 yards, use the following formula:
Divide the distance (number of yards) by 100. The resulting number, when multiplied
by the click value stated on the windage and elevation dial plates, will yield the actual
click value of the scope at the shooting distance.
Distance (yards) / 100 = N
N x Stated Click Value = Actual Click Value
Once zeroing of the weapon is completed,
replace the windage and elevation caps.
To place the center of the reticle (red)
on the point of impact (orange), turn
the elevation turret counter-clockwise
to raise the point of impact. Then, turn
the windage turret counter-clockwise
to move the point to impact to the left.
