USER MANUAL
11
FORCE V
WWW.BROTHERS-SONS.DK
Software vers. 1_3_00
POWER UP
After power ON, the unit will be operational after 10 seconds.
During the power up the unit will do selftests, including fan test.
SPECIAL FUNCTIONS
Within the first 10 seconds PRESS and HOLD....
...ENTER till the display reads “MAN 00” to reset stored manual value to zero.
...MENU till the display reads “RESET” to reset all modes and adress settings to default.
...DOWN till the menua reads “INTRO” to show the units Software Version.
DISPLAY ORIENTATION
To flip orientation off display press UP and DOWN simultaneously.
MODE FEATURES EXPLAINED (Default settings in bold)
Resolution: 8 bit:
Less DMX channels used.
16 bit:
Smoother fades.
Response: Slow:
Fades between values. Smoother fades.
Fast:
Snaps between values. Fast operation.
Curve:
Square:
Dimmer curve designed for LEDs
Linear:
Standard dimmer curve
Strobe:
OFF:
Less DMX channels used.
ON:
Strobe
function
added.
noDMX: HOLD:
If DMX signal is lost, the unit will maintain the last value received.
OFF:
If DMX signal is lost, the unit will go to 0% light level.
MAN:
If DMX signal is lost, the unit will go to the saved manual light level
Display: OFF 2n:
The display will switch off after 2 minutes of idle operation.
ON:
The display will always be on.
software v: 2_0_05
