USER MANUAL
10
FORCE V
WWW.BROTHERS-SONS.DK
SOFTWARE MENU
Default values indicated by bold font
Addr 1 DMX adress value 1 - 512
M
ode Resolution 8 bit resolution
16 bit resolution
Response Slow (fade between values)
Fast (snap between values)
Curve Square dimmer curve
Linear dimmer curve
Strobe OFF
On - (adds 2 strobe channels)
Fan HIGH - No fan speed limit
LOW - Fan speed limited (Silent)
noDMX Action when loss of DMX signal:
HOLD - last received DMX value
OFF - Sets output to zero
MAN - Go to Manual DMX value
Display OFF 2n - Display off after 2 minutes
ON - Display always on
Tools Ver Shows software version
HW Ver Shows hardware version
L Temp LED temperature
DMX In 3 first digits shows DMX adress
3 last digits shows DMX value
Reset Confirm (Reset unit by pressing enter)
test Fan Fan test
First 2 digits - set fan speed level 0 - 31
Last 3 digits - RPS (rounds per second)
test display Display test - cycles through all segments of the display
Software vers. 2_0_05
Log Log C° Minimum and maximum logged temperature in °C
UP and DOWN scrolls min. and max.
on time PSU on time in hours
on LED LED on time in hours
on Cnt Counts number of times unit has been switched on
Serial Internal serial number used as service number
PSU U PSU voltage in Volts
DMX HZ DMX refresh rate
DMX CH No. of DMX ch. transmitted by controller
DMX br Break lenght of DMX in microseconds
Manual 0 Manual intensity 0 - 100%
Intensity saved when pressing ENTER
(Display is always on in manual mode)
software v: 2_0_05
