ToughSTICK™ RGBAW Manual - Rev. C
Copyright (c) 2012 Blizzard Lighting, LLC
DMX Mode
Allows the unit to be controlled by any universal DMX controller.
1.) The default mode for the fixture is DMX, which appears as
A001
on the LED Readout. To
select a different DMX address, using the button, select
Addr
,then hit
Use the
Stand-Alone, Master/Slave Modes:
Allows a single or Master/Slaved units to run factory installed programs at user selectable speeds.
1.) To set the fixture in Flash/Fade mode, select
FLAS or FAdE
To confirm, press the
2.) Now, select the flash or fade speed using button to reach
SP--
, then hit
The display reads
SP15
(slowest) to
SP00
(fastest), then press the
confirm.
3.) To use the fixture in automatic mode, select
ASC-
, then press the
confirm.
4.) Adjust the speed of the chase as above using
SP15
(slowest) to
SP00
(fastest) then
press the
5.) To set the fixture as a slave unit, select
SLAV
, and hit
then flash
SLAV
. Once it stops flashing, the fixture is in slave mode.
Standalone (Program) Mode:
Allows a single unit to display a variety of colors and programs without a DMX controller.
1.) To set the fixture in manual mode, select
Pr--
.
To confirm, press the
2.) Now, select the program by using the
Pr00-
Pr15
. To confirm, press the
Pr00 = Red
Pr01 = Green
Pr02 = Blue
Pr03 = Amber
Pr04 = White
Pr05 = R+G+B
Pr06 = R+G+B+W+A
Pr07 = Program #1
Pr08 = Program #2
Pr09 = Program #3
Pr10 = Program #4
Pr11 = Program #5
Pr12 = Program #6
Pr13 = Program #7
Pr14 = Program #8
Pr15 = Pr07-Pr14 Chase
Program Descriptions:
Program #1: Red + G/B/A/W Segment Chase
Program #2: R/G/B/A/W Full Bar Chase
Program #3: R/G/B/A/W 3-Segment Chase #1
Program #4: Red+Green + B/A/W Segment Chase
Program #5: Red/Green/Blue Segment Chase
Program #6: Blue/Amber/White Segment Chase
Program #7: R/G/B/A/W In and Out - Full Bar
Program #8: R/G/B/A/W 3-Segment Chase #2
