ProPAR 7.6 Manual Rev. A © 2014 Blizzard Lighting, LLC
2. MEET THE PROPAR SEVEN.6™ LED PAR
MAIN FEATURES:
• User selectable 3/5/8 or 11 DMX channels
• Full color mixing in standalone, master/slave and DMX modes
• Built-in automated programs via master/slave
• Built-in sound activated programs via master/slave
• Easy to use LED digital control panel
• 3-pin male input and 3-pin female output
• Dual mounting yoke allows flexibility in positioning
• Aluminum die-casting housing
OPTICAL:
• Beam Angle: 25°
• 4,580 Lux @ 1m, 1,240 Lux @ 2m (full on)
• 1000hz flicker-free LED drivers
• Light Source: 7* 15-watt 6-in-1 LEDs, 100,000 hours
CONTROL:
• USITT DMX-512 (3/6/8/11 Channels)
• 3-pin Input/Output
• LED 4-button control panel
DMX Quick Reference
Channel 11-Channel 8-Channel 6-Channel 3-Channel
1 Dimmer Dimmer Red Intensity Hue
2 Red Intensity Red Intensity Green Intensity Saturation
3 Green Intensity Green Intensity Blue Intensity Value
4 Blue Intensity Blue Intensity Amber Intensity ---
5 Amber Intensity Amber Intensity White Intensity ---
6 White Intensity White Intensity UV Intensity ---
7 UV Intensity UV Intensity --- ---
8 Strobe Dimming Modes --- ---
9 Built-in Programs --- --- ---
10 Speed --- --- ---
11 Dimming Modes --- --- ---
