The PinUp™ RGBW Pinspot Rev. A

Copyright (c) 2012 Blizzard Lighting, LLC

Tech Specs!

Weight & Dimensions

Length

2.63 inches (66.41 mm)

Width

4.75 inches (120.18 mm)

Weight

0.9 pounds (66.41 kg)

Power

Operating Voltage

90-230VAC, 12VDC 2.0A

Current

1.0A

Light Source

LED

1* 10-watt RGBW LED, 100,000 hours

Optical

Beam Angle

Luminous Intensity

1200 Lux/1m

Thermal

Max. Operating Temp.

104 degrees F (40 degrees C) ambient

Control

Protocol

USITT DMX-512

DMX Channels

6 Channels

Input

3-pin XLR Male

Output

3-pin XLR Female

Other Operating

Modes

Standalone, Master/Slave, Color Preset

Coolness Factor

Leventy Billion Percent

Warranty

2-year limited warranty, does not cover mal-

function caused by damage to LED’s.
