Blizzard Lighting PinUp RGBW LED Pinspot - Manual (Page 13)

Page 13
The PinUp™ RGBW Pinspot Rev. A Copyright (c) 2012 Blizzard Lighting, LLC
DMX Values In-Depth (6-Channel Mode)
Channel Value What It Does
1 000 <--> 131
032 <--> 239
240 <--> 255
Dimmer (0% <--> 100%)
Strobe (Slow <--> Fast)
No Function
2 000 <--> 255 Red Intensity (0% <--> 100%)
3 000 <--> 255 Green Intensity (0% <--> 100%)
4 000 <--> 255 Blue Intensity (0% <--> 100%)
5 000 <--> 255 White Intensity (0% <--> 100%)
6 000 <--> 002
003 <--> 031
032 <--> 063
064 <--> 079
080 <--> 095
096 <--> 111
112 <--> 128
129 <--> 143
144 <--> 159
160 <--> 175
176 <--> 191
192 <--> 207
208 <--> 223
224 <--> 255
No Function
Run 1 Program
Run 2 Program
Run 3 Program
Run 4 Program
Run 5 Program
Run 6 Program
Run 7 Program
Run 8 Program
Run 9 Program
Run A Program
Run B Program
Run C Program
Blackout
Troubleshooting
Symptom Solution
Beam is Dim Check optical system and clean excess dust/grime. Also
ensure that the 220V/110V switch is in the correct position,
if applicable.
No Light Output Check to ensure fixture is operating under correct mode, IE
sound active/auto/DMX/Etc., if applicable. Contact service
for more information.
Chase Speed
Too Fast/Slow
Check to ensure proper setup of speed adjustment.
No Power Check AC cord and circuit for malfunction.
Fixture Not
Responding /
Responding Er-
raticly
Make sure all connectors are seated properly and securely.
Use Only DMX Cables.
Install a Terminator.
Check all cables for defects.
Reset fixture(s).
If your problem isn’t listed, or if problems persist,
please contact support: [email protected].
