Page 6, Figure 2: the rear connections – Blizzard Lighting Memerizor RGB 3D Laser(Rev A) User Manual
Page 6
Page 6
Mezmerizor™ Manual - Rev. A
(c) 2013 Blizzard Lighting, LLC
Figure 1: The Mezmerizor™ Pin-Up Picture
Attractive Blue
Colored Aluminum Casing
Secure Mounting Bracket
& Adjustment Screws
Figure 2: The Rear Connections
Laser Output (Aperture)
Power Indicator
Microphone
Mic Indicator
On/Off Switch
AC Power Input
Mic Sensitivity
Cooling Fan
DMX In DMX Out
Dipswitches
