G60™ Manual Rev. A Copyright (c) 2011 Blizzard Lighting, LLC
2. MEET THE G60™ SPOT
CONTROL FEATURES
15-channel DMX LED moving yoke •
Pan: 540º Tilt: 263º •
Color wheel: 7 colors + white •
Rainbow color spin at variable speeds •
7 interchangeable, rotating, indexing slot-n-lock gobos + open •
7 static gobos (Gobo Wheel #2) •
Ability to layer gobos for multicolor/multi-textured effects. •
Gobo wheel spin at variable speeds •
3-facet rotating prism •
Variable electronic strobe •
Variable electronic dimmer (0 – 100%) •
Remote focus via DMX (2m~infi nity) •
Remote fi xture reset •
Multiple built-in automated & sound activated programs •
User-programmable built-in programs •
ADDITIONAL FEATURES
Lux: 27,800 @ 1m, 6,240 @ 2m •
Gobo size: 25mm outside, 22mm image, 1.2mm max thickness •
Beam Angle: 15º •
Light source: 60W White, US-Made Luminus CST-90 LED, 50,000 hrs •
DMX Quick Reference
Channel What It Does
1 Strobe
2 Dimmer
3 Pan
4 Pan Fine (16-Bit)
5 Tilt
6 Tilt Fine (16-Bit)
7 Motor Speed
8 Color Wheel
9 Gobo Wheel #1
10 Gobo Wheel #1 Index/Rotation
11 Gobo Wheel #2
12 Focus
13 Prism
14 Prism Rotation
15 Reset
