G60™ Manual Rev. A
Copyright (c) 2011 Blizzard Lighting, LLC
4. OPERATING ADJUSTMENTS
The Control Panel
All the goodies and different modes possible with the G60™ are ac-
cessed by using the control panel on the front of the fi xture. There are
4 control buttons below the LCD display which allow you to navigate
through the various control panel menus.
Access control panel functions using the four panel buttons located
directly underneath the LCD Display.
The Control Panel LCD Display shows the menu items you select from
the menu map on page #11. When a menu function is selected, the
display will show immediately the fi rst available option for the selected
menu function. To select a menu item, press
Use the
menu options. Press the
currently displayed or to enable a menu option. To return to the previ-
ous option or menu without changing the value, press the
button.
Control Panel Menu Structure
Main Function
Selection
What It Does...
DMX Address
=000 <-> 511
Sets the DMX address
* Indicates the unit is receiving DMX signal
MASTER
= EFFECT 00
Sets the unit in Sound Active Mode
= EFFECT 01
Sets the unit in Auto “Fast” Mode
= EFFECT 02
Sets the unit in Auto “Slow” Mode
FOLLOW
N/A
Sets the fi xture in Slave Mode
PAN_R
= OFF / =ON
Reverses the fi xture’s Pan movement
TILT_R
= OFF / =ON
Reverses the fi xture’s Tilt movement
