DMX Channel Values
Channel Channel Value Does...
1 000 <-> 239
240 <-> 255
Strobe
Strobe (Slow <--> Fast)
Open
2 000 <-> 255 Dimmer (0 <--> 100%)
3 000 <-> 255 Pan
4 000 <-> 255 Pan Fine (16-Bit Pan)
5 000 <-> 255 Tilt
6 000 <-> 255 Tilt Fine (16-Bit Tilt)
7 000 <-> 255 Motor Speed (Fast <--> Slow)
8
000 <-> 015
016 <-> 031
032 <-> 047
048 <-> 063
064 <-> 079
080 <-> 095
096 <-> 111
112 <-> 127
128 <-> 191
192 <-> 255
Color
Open
Color 1
Color 2
Color 3
Color 4
Color 5
Color 6
Color 7
Color Wheel Scroll (Clockwise, Slow <-> Fast)
Color Wheel Scroll (Counter-Clockwise, Fast <-> Slow)
9
000 <-> 015
016 <-> 031
032 <-> 047
048 <-> 063
064 <-> 079
080 <-> 095
096 <-> 111
112 <-> 127
128 <-> 191
192 <-> 255
Gobo Wheel #1
Open
Gobo 1
Gobo 2
Gobo 3
Gobo 4
Gobo 5
Gobo 6
Gobo 7
Color Wheel Scroll (Clockwise, Slow <-> Fast)
Color Wheel Scroll (Counter-Clockwise, Fast <-> Slow)
10
000 <-> 004
005 <-> 127
128 <-> 131
132 <-> 255
Gobo Rotation
No function
Gobo Indexing (0 <--> 360 degrees)
Clockwise (Slow <--> Fast)
Counter-clockwise (Slow <-> Fast)
11
000 <-> 015
016 <-> 031
032 <-> 047
048 <-> 063
064 <-> 079
080 <-> 095
096 <-> 111
112 <-> 127
128 <-> 191
192 <-> 255
Gobo Wheel #2
Open
Gobo 1
Gobo 2
Gobo 3
Gobo 4
Gobo 5
Gobo 6
Gobo 7
Color Wheel Scroll (Clockwise, Slow <-> Fast)
Color Wheel Scroll (Counter-Clockwise, Fast <-> Slow)
12
000 <-> 255
Focus
Near <-> Far
13 000 <-> 127
128 <-> 255
Prism
Prism Out
Prism In
14
000 <-> 007
008 <-> 119
120 <-> 231
232 <-> 239
240 <-> 247
248 <-> 255
Prism Rotation
No function
Clockwise (Slow <--> Fast)
Counter-clockwise (Slow <-> Fast)
Prism Rotation 90 degrees
Prism Rotation 180 degrees
Prism Rotation 360 degrees
15 000 <-> 254
255 <-> 255
Reset
No Function
Reset (Hold for 5 seconds)
