Flurry TRI Manual Rev. A
Copyright (c) 2011 Blizzard Lighting, LLC
DMX Quick Reference (5-Channel Mode)
Channel
What It Does
1
Pan
2
Tilt
3
Dimmer & Strobe
4
Color Macros
5
Reserved
Figure 1: The Flurry Pin-Up Picture
High Power
LED’s
Control Panel
LED
Readout
Head
Figure 2: The Rear Connections
AC Power
Fuse Cover
110V/220V Switch
DMX In
DMX Out
Easy Controller (CA-9)
