Flurry TRI Manual Rev. A Copyright (c) 2011 Blizzard Lighting, LLC
Stand-Alone Mode (Auto Mode):
Allows a single unit to run to a factory installed program at one of two speeds.
1.) To set the fi xture in auto mode fast, select .
Once confi rmed the display reads .
2.) To set the fi xture in auto mode Slow, select .
Once confi rmed the display reads .
Master/Slave Mode (Auto or Sound Active):
Allows you to link up to 32 units together without a controller.
1.) Use standard DMX cables to daisy chain your units together via the DMX con-
nector on the rear of the units. It may be necessary to use a terminator at the
last fi xture. For more information about terminators, see page 8.
2.) Choose a unit to function as the Master. Select NAFA/NASL or NStS (see be-
low for readout) depending upon which master mode you want. The master unit
must be the fi rst unit. Finally, chain the units together using DMX cable.
Master Auto or .
Master Sound becomes when confi rmed.
3.) Select slave function by using the / keys to reach SLAv in
the Master/Auto menu on the slave units, and they will react in the same as the
Master.
Slave becomes when confi rmed.
Easy Controller Mode
Allows you to use the optional CA-9 Easy Controller for basic control functionality.
1.) Connect the CA-9 Easy Controller to the controller port on the rear panel of
the unit.
2.) Select the Easy Controller function by using the / keys to
reach NStc in the menu structure.
Easy Control becomes when confi rmed.
3.) In Easy Controller Mode, the fi xture will react as follows:
Button What it Does...
Standby Blackout.
Function 1st click = Strobe On, 2nd click = Strobe Off.
Mode 1st click = Sound Active Mode (Remote LED will be on).
2nd click = Auto Mode (LED will be off).
DMX Mode
Allows the unit to be controlled by any universal DMX controller. If you are unfamiliar with
DMX, please read the DMX Primer on page #17.
1.) The default mode for the fi xture is DMX, which appears as on the
LED Readout.
