BlockHead™ User Manual Rev. B (c) 2014 Blizzard Lighting, LLC
Manual Color Adjustment
Allows you to mix your own global custom color.
1.) Use the button to scroll to Set Run MANUAL, then use the
buttons to display any of Red, Green, Blue, or White settings. Push the button while
highlighting any to display the color intensity range settings from 000 (off) to 255 (100%).
Use the buttons to adjust the intensity, then push to confi rm your
choice.
System Reset
To automatically reset the X/Y motors to automatically realign the moving head position, use the
DMX Values In-Depth (16/20/116-Channel Mode)
16CH 20CH 116CH Channel Value What it does
CH1 CH1 CH1
000 <--> 020
021 <--> 127
128 <--> 191
192 <--> 255
043
Pan
No function
Pan Position
Pan Rotate CW Slow <--> Fast
Pan Rotate CCW Slow <--> Fast
Center Default
CH2 CH2 CH2
000 <--> 127
128 <--> 191
192 <--> 255
053
Tilt
Tilt Position
Tilt Rotate CW Slow <--> Fast
Tilt Rotate CCW Slow <--> Fast
Center Default
CH3 CH3 CH3 000 <--> 255 Pan Fine
CH4 CH4 CH4 000 <--> 255 Tilt Fine
CH5 CH5 CH5
000 <--> 255
Pan, Tilt Speed Adjustment
Track (Fast) <--> Slow
CH6 CH6 CH6
000 <--> 047
048 <--> 063
064 <--> 079
080 <--> 095
096 <--> 111
112 <--> 127
128 <--> 143
144 <--> 159
160 <--> 175
176 <--> 191
192 <--> 207
208 <--> 223
224 <--> 239
240 <--> 245
246 <--> 255
Built-in Programs (images)
No function
1 LED Chase Pattern #1
1 LED Chase Pattern #2
1 LED Chase Pattern #3
2 LED Chase Pattern
3 LED Chase Pattern
4 LED Chase Pattern
Image 1 - Group Pattern - Bars
Image 2 - Group Pattern - Snake
Image 3 - Group Pattern - Square
Image 4 - Group Pattern - Diagonal
Image 5 - Group Pattern - Random Dots
Sound Mode
Sound Mode with Movement
All Programs (ch9 controls speed)
