BladeRunner™ White User Manual Rev. A (c) Copyright 2014 Blizzard Lighting, LLC
2. MEET THE BLADERUNNER™ WHITE
MAIN FEATURES:
• 4x moving heads, each with 1x CREE® 10w White LED
• Blazing fast 540° pan and 270° tilt
• User selectable 9 or 19 DMX channels
• Narrow 2 degree beam angle
• Outstanding quad beam effects
• Built-in sound active programs
• Built-in automated programs via master/slave
• Built-in sound activated programs via master/slave
• 3-pin male input and 3-pin female output
• PowerCon™ compatible AC power In/Out connectors
CONTROL:
• USITT DMX-512 (9/19 Channels)
• 3-pin Input/Output
• 4-button menu with LCD display
DMX Quick Reference (9-Channel Mode)
Channel What is does
1
Dimmer (0% <--> 100%)
2 Strobe (slow <--> fast)
3 Built-in Programs + Sound Active
4 Program Speed (slow <--> fast)
5 Pan
6 Tilt
7 Pan Speed (fast <--> slow)
8 Tilt Speed (fast <--> slow)
9 Motor Reset (246-255)
