BladeRunner™ White User Manual Rev. A (c) Copyright 2014 Blizzard Lighting, LLC
4. OPERATING ADJUSTMENTS
The Control Panel
All the goodies and different modes possible with the BladeRunner™ White are accessed by
using the control panel on the front of the fixture. There are 4 control buttons below the
LCD display which allow you to navigate through the various control panel menus.
Main Menu
To navigate through the LCD control panel main menu, use the
through the various top level menu options. Then to scroll through sub-menu options, use
the buttons. Push the button to save any changes made.
MENU ENTER DOWN UP
Control Panel Menu Structure
Address 001-512 DMX Address
CHND 9CH 9 Channel DMX Mode
19CH 19 Channel DMX Mode
AUTO STOP/RUN Auto Mode (slower color changing)
AUTO 1 STOP/RUN Auto Mode (faster color changing)
AUDIO STOP/RUN Sound Active Mode
COLOR White 1 Head 1 - White (0-255)
White 2 Head 2 - White (0-255)
White 3 Head 3 - White (0-255)
White 4 Head 4 - White (0-255)
Shut Strobe Rate (0-255)
PROGRAM 01-10 Built-in Programs
PRO-Movement ON/OFF Auto Movement On/Off
SPEED Speed Settings
Movement Movement Speed (001-255)
Color Color Speed (001-255)
LED ON/OFF LCD Backlight On/Off
VERSION V1.0.0 Firmware Version
RESET Yes? Fixture Reset
