1.5 Cable Requirements
•
10Base T: Category 3, 4, and 5 UTP cable can be used. Maximum
distance for each UTP cable is approximately 100 meters (328 feet).
•
10Base 2: The connection uses RG-58 A/U thin coaxial cable.
Requires a T connector to connect the cable to the BCN port. The last
PC in the segment will require a 50-Ohm terminator to be attached to
the open arm of the T connector.
1.6 The Driver Disk Contains the Following:
Directory Contents
README.TXT This
file.
\ENABLE Enable
program.
\NetWare
Novell NetWare ODI driver programs.
\WFW31
Driver (NDIS v2.0) is used for Windows/Workgroup 3.1.
\WFW311
Driver (NDIS v3.0) is used for Windows/Workgroup 3.11.
\WIN95
Installation guide for Windows 95.
\MSLANMAN.DOS
Driver (NDIS v2.0) is used for Microsoft LAN Manager (DOS).
\MSLANMAN.OS2
Driver (NDIS v2.0) is used for Microsoft LAN Manager (OS2).
\PACKET
Packet Driver Program.
\LANTASTI
LANtastic/AI 4.x, 5.x and 6.0 installation guide.
\PCNFS
Driver (NDIS v2.0) is used for PC-NFS 5.1 System.
\PATHWORK
Driver (NDIS v2.0) is used for PATHWORK System.
\VINES
Driver (NDIS v2.0) is used for VINES System.
\NDIS
IBM LAN SERVER v4.0 (DOS LAN Services).
IBM LAN SERVER v3.0 (DOS LAN Services).
\WINNT351
Driver (NDIS v3.1) is used for Windows NT 3.51 workstation.
In the ENABLE directory
ECARD.EXE file--------- Card enabler/Socket services client for DOS system.
ECARDCS.EXE file ---- Card services client for DOS system.
ECARDHP.EXE file ----- Socket services enabler for HP Omnibook 300.
ECARDOS2.OS2 file --- Card enabler/Socket services client for OS2 system.
TMI.CLB file ------------- LAN Card library file for Systemsoft 3.1.
The README.TXT file is in the root directory on the drivers disk.
Specific drivers are in there own directories. Each directory also contains a
text file, which contains the installation for that specific driver. The Enable
directory contains the Card Service and Socket Service files.
