36
Appendix E
Application Matrix for Bendix ® 360cc Single Cylinder and 720cc Twin Cylinder
Compressors for International Maxxforce ® Big Bore Engines
This useful Compressor Application Guide is a simple point system
using vehicle configuration and vocation options to help calculate the
Bendix
® compressor right for your vehicle. Review items 1 – 13, fill in
the applicable points on each line, then refer to the application grid on the
next page for the Bendix compressor selections that can meet your vehicle’s
intended use. When completing the worksheet, if a particular entry is not
valid for your application, enter zero on that line. See the examples of how
to use this calculator at the end of the next page.
Note 1: Vehicles equipped with either bulk offloading, central tire inflation or used in City Transit bus applications are required to use a 720cc
compressor. No points need to be calculated. Refer to next page for proper compressor selection.
Note 2: It is recommended that a 720cc compressor be used on all Fire Truck and Aircraft Rescue applications to reduce the complexity of the “Fast
Fill” system.
Vehicle Configuration Points
1. Vehicle is equipped with bulk offloading or central tire inflation (See Note 1)
2. For every axle (tractor & trailer – including lifts): Add 1.0 point/axle 4
3. For each non-steerable lift axle (additional points): Add 1.0 point/axle 4
4. For each steerable lift axle (additional points): Add 0.5 points/axle 4
5. Tractor and/or trailer is equipped with air suspension Add 0.5 points 4
Vocation Options (Select the description that best fits)
6. Vehicle is used as a city transit bus (See Note 1)
7. Vehicle is used for pickup & delivery
a) Non-fuel hauler:
add 0.5 points 4
b) Fuel hauler:
add 1.0 point 4
8. Vehicle is used for residential refuse
• Vehicle with a work brake Add 4.5 points 4
• Vehicle without a work brake Add 7.5 points 4
9. Vehicle is used for rural or commercial refuse Add 3.5 points 4
10. Vehicle is used as a yard or terminal jockey Add 7.5 points 4
11. Vehicle is a dump truck, a concrete mixer, or is used in
logging or construction
Add 2.0 points 4
12. Vehicle is a fire truck -- “Fast Fill” system (See Note 2) Add 6.0 points 4
13. Vehicle is used for line haul Add 0.0 points 4 0
Total Score
(Add lines 1 – 13 and use that sum on page two of this guide)
