APPENDIX A: J1587 SID and FMI Codes and their Bendix Blink Code Equivalents
SID (J1587)
FMI (J1587)
General
Bendix Blink Code
Equivalent(s)
Diagnostic Trouble Code Description
(1st
Digit)
(2nd
Digit)
12
5
Pressure Modulator Valve
17
7
AA Right PMV CMN Open Circuit
12
13
Pressure Modulator Valve
17
8
AA Right PMV Configuration Error
13
2
Miscellaneous
12
4
Retarder Relay Open Circuit or Shorted to Ground
13
3
Miscellaneous
12
5
Retarder Relay Circuit Shorted to Voltage
17
14
Miscellaneous
12
3
ATC Disabled or Dynamometer Test Mode Active
17
14
Miscellaneous
12
9
ATC Disabled to Prevent Brake Fade
18
13
TCV
18
4
TCV Configuration Error
18
3
TCV
18
2
TCV Solenoid Shorted to Voltage
18
4
TCV
18
1
TCV Solenoid Shorted to Ground
18
5
TCV
18
3
TCV Solenoid Open Circuit
22
7
Miscellaneous
12
11
Wheel Speed Sensors Reversed on an Axle
23
2
Miscellaneous
12
6
ABS Warning Lamp Circuit
42
3
Pressure Modulator Valve
7
5
SA Left PMV HLD Solenoid Shorted to Voltage
42
4
Pressure Modulator Valve
7
4
SA Left PMV HLD Solenoid Shorted to Ground
42
5
Pressure Modulator Valve
7
6
SA Left PMV HLD Solenoid Open Circuit
43
3
Pressure Modulator Valve
8
5
SA Right PMV HLD Solenoid Shorted to Voltage
43
4
Pressure Modulator Valve
8
4
SA Right PMV HLD Solenoid Shorted to Ground
43
5
Pressure Modulator Valve
8
6
SA Right PMV HLD Solenoid Open Circuit
44
3
Pressure Modulator Valve
9
5
DA Left PMV HLD Solenoid Shorted to Voltage
44
4
Pressure Modulator Valve
9
4
DA Left PMV HLD Solenoid Shorted to Ground
44
5
Pressure Modulator Valve
9
6
DA Left PMV HLD Solenoid Open Circuit
45
3
Pressure Modulator Valve
10
5
DA Right PMV HLD Solenoid Shorted to Voltage
45
4
Pressure Modulator Valve
10
4
DA Right PMV HLD Solenoid Shorted to Ground
45
5
Pressure Modulator Valve
10
6
DA Right PMV HLD Solenoid Open Circuit
46
3
Pressure Modulator Valve
16
5
AA Left PMV HLD Solenoid Shorted to Voltage
46
4
Pressure Modulator Valve
16
4
AA Left PMV HLD Solenoid Shorted to Ground
46
5
Pressure Modulator Valve
16
6
AA Left PMV HLD Solenoid Open Circuit
47
3
Pressure Modulator Valve
17
5
AA Right PMV HLD Solenoid Shorted to Voltage
47
4
Pressure Modulator Valve
17
4
AA Right PMV HLD Solenoid Shorted to Ground
47
5
Pressure Modulator Valve
17
6
AA Right PMV HLD Solenoid Open Circuit
48
3
Pressure Modulator Valve
7
2
SA Left PMV REL Solenoid Shorted to Voltage
48
4
Pressure Modulator Valve
7
1
SA Left PMV REL Solenoid Shorted to Ground
48
5
Pressure Modulator Valve
7
3
SA Left PMV REL Solenoid Open Circuit
49
3
Pressure Modulator Valve
8
2
SA Right PMV REL Solenoid Shorted to Voltage
49
4
Pressure Modulator Valve
8
1
SA Right PMV REL Solenoid Shorted to Ground
49
5
Pressure Modulator Valve
8
3
SA Right PMV REL Solenoid Open Circuit
50
3
Pressure Modulator Valve
9
2
DA Left PMV REL Solenoid Shorted to Voltage
50
4
Pressure Modulator Valve
9
1
DA Left PMV REL Solenoid Shorted to Ground
50
5
Pressure Modulator Valve
9
3
DA Left PMV REL Solenoid Open Circuit
51
3
Pressure Modulator Valve
10
2
DA Right PMV REL Solenoid Shorted to Voltage
51
4
Pressure Modulator Valve
10
1
DA Right PMV REL Solenoid Shorted to Ground
51
5
Pressure Modulator Valve
10
3
DA Right PMV REL Solenoid Open Circuit
52
3
Pressure Modulator Valve
16
2
AA Left PMV REL Solenoid Shorted to Voltage
52
4
Pressure Modulator Valve
16
1
AA Left PMV REL Solenoid Shorted to Ground
52
5
Pressure Modulator Valve
16
3
AA Left PMV REL Solenoid Open Circuit
53
3
Pressure Modulator Valve
17
2
AA Right PMV REL Solenoid Shorted to Voltage
53
4
Pressure Modulator Valve
17
1
AA Right PMV REL Solenoid Shorted to Ground
53
5
Pressure Modulator Valve
17
3
AA Right PMV REL Solenoid Open Circuit
55
2
Miscellaneous
12
2
Stop Lamp Switch Defective
55
7
Miscellaneous
12
1
Stop Lamp Switch Not Detected
79
13
Miscellaneous
12
10
Tire Size Out of Range (Front to Rear)
93
3
Miscellaneous
12
8
PMV/TCV/Diff Lock Common Shorted to Voltage
93
4
Miscellaneous
12
7
PMV/TCV/Diff Lock Common Shorted to Ground
