APPENDIX A: J1587 SID and FMI Codes and their Bendix Blink Code Equivalents
SID (J1587)
FMI (J1587)
General
Bendix Blink Code
Equivalent(s)
Diagnostic Trouble Code Description
(1st
Digit)
(2nd
Digit)
1
1
Wheel Speed Sensor
2
1
SA Left WSS Excessive Air Gap
1
2
Wheel Speed Sensor
2
3
SA Left WSS Open or Shorted
1
7
Wheel Speed Sensor
2
5
SA Left WSS Wheel End
1
8
Wheel Speed Sensor
2
6
SA Left WSS Erratic Sensor Signal
1
10
Wheel Speed Sensor
2
4
SA Left WSS Loss of Sensor Signal
1
13
Wheel Speed Sensor
2
7
SA Left WSS Tire Size Calibration
1
14
Wheel Speed Sensor
2
2
SA Left WSS Output Low @ Drive-Off
2
1
Wheel Speed Sensor
3
1
SA Right WSS Excessive Air Gap
2
2
Wheel Speed Sensor
3
3
SA Right WSS Open or Shorted
2
7
Wheel Speed Sensor
3
5
SA Right WSS Wheel End
2
8
Wheel Speed Sensor
3
6
SA Right WSS Erratic Sensor Signal
2
10
Wheel Speed Sensor
3
4
SA Right WSS Loss of Sensor Signal
2
13
Wheel Speed Sensor
3
7
SA Right WSS Tire Size Calibration
2
14
Wheel Speed Sensor
3
2
SA Right WSS Output Low @ Drive-Off
3
1
Wheel Speed Sensor
4
1
DA Left WSS Excessive Air Gap
3
2
Wheel Speed Sensor
4
3
DA Left WSS Open or Shorted
3
7
Wheel Speed Sensor
4
5
DA Left WSS Wheel End
3
8
Wheel Speed Sensor
4
6
DA Left WSS Erratic Sensor Signal
3
10
Wheel Speed Sensor
4
4
DA Left WSS Loss of Sensor Signal
3
13
Wheel Speed Sensor
4
7
DA Left WSS Tire Size Calibration
3
14
Wheel Speed Sensor
4
2
DA Left WSS Output Low @ Drive-Off
4
1
Wheel Speed Sensor
5
1
DA Right WSS Excessive Air Gap
4
2
Wheel Speed Sensor
5
3
DA Right WSS Open or Shorted
4
7
Wheel Speed Sensor
5
5
DA Right WSS Wheel End
4
8
Wheel Speed Sensor
5
6
DA Right WSS Erratic Sensor Signal
4
10
Wheel Speed Sensor
5
4
DA Right WSS Loss of Sensor Signal
4
13
Wheel Speed Sensor
5
7
DA Right WSS Tire Size Calibration
4
14
Wheel Speed Sensor
5
2
DA Right WSS Output Low @ Drive-Off
5
1
Wheel Speed Sensor
14
1
AA Left WSS Excessive Air Gap
5
2
Wheel Speed Sensor
14
3
AA Left WSS Open or Shorted
5
7
Wheel Speed Sensor
14
5
AA Left WSS Wheel End
5
8
Wheel Speed Sensor
14
6
AA Left WSS Erratic Sensor Signal
5
10
Wheel Speed Sensor
14
4
AA Left WSS Loss of Sensor Signal
5
13
Wheel Speed Sensor
14
7
AA Left WSS Tire Size Calibration
5
13
Wheel Speed Sensor
14
10
AA Left WSS Configuration Error
5
14
Wheel Speed Sensor
14
2
AA Left WSS Output Low @ Drive-Off
6
1
Wheel Speed Sensor
15
1
AA Right WSS Excessive Air Gap
6
2
Wheel Speed Sensor
15
3
AA Right WSS Open or Shorted
6
7
Wheel Speed Sensor
15
5
AA Right WSS Wheel End
6
8
Wheel Speed Sensor
15
6
AA Right WSS Erratic Sensor Signal
6
10
Wheel Speed Sensor
15
4
AA Right WSS Loss of Sensor Signal
6
13
Wheel Speed Sensor
15
7
AA Right WSS Tire Size Calibration
6
13
Wheel Speed Sensor
15
10
AA Right WSS Configuration Error
6
14
Wheel Speed Sensor
15
2
AA Right WSS Output Low @ Drive-Off
7
5
Pressure Modulator Valve
7
7
SA Left PMV CMN Open Circuit
7
13
Pressure Modulator Valve
7
8
SA Left PMV Configuration Error
8
5
Pressure Modulator Valve
8
7
SA Right PMV CMN Open Circuit
8
13
Pressure Modulator Valve
8
8
SA Right PMV Configuration Error
9
5
Pressure Modulator Valve
9
7
DA Left PMV CMN Open Circuit
9
13
Pressure Modulator Valve
9
8
DA Left PMV Configuration Error
10
5
Pressure Modulator Valve
10
7
DA Right PMV CMN Open Circuit
10
13
Pressure Modulator Valve
10
8
DA Right PMV Configuration Error
11
5
Pressure Modulator Valve
16
7
AA Left PMV CMN Open Circuit
11
13
Pressure Modulator Valve
16
8
AA Left PMV Configuration Error
