23
ABS Component
Harness Connector
Shell
Harness Terminal Wire Seal Lock Plug
ECU Deutsch DT (Deutsch) Socket (Deutsch) W12S-P012 (Deutsch) 114017 (Deutsch)
DT06 12SA-BK01 (Grey) 0462-201-16141
DT06 12SB-BK01 (Black)
DT06 12SC-B016 (Green)
Relay Valve Bayonett Socket (Amp) Seal (Amp)
26570 14414-627-626
Wheel End Sensor 2-Pin Kostal
w/overmold
MPSI Scan Tool Diagnostic Port (Deutsch) Pin (Deutsch) 114017 (Deutsch)
HD10-6-12P 0460-204-12141
Warning Light
Power Cable (Packard) Socket (Packard) Seal (Packard) 12010300 (Packard)
ECU Side 12124580 12015323
12034342 12010293
Power Cable (Packard) Pin (Packard) Seal (Packard) 12010300 (Packard)
Trailer Harness Side 12124582 12015323
12065158 12010293
ABS
N/A
N/A N/A N/A
N/A N/A
N/A
N/A N/A
N/A
N/A N/A
N/A N/A
N/A
N/A
N/A
Length Eaton Part No.
2 meters 300090
3 meters 300091
5 meters 300092
8 meters 300093
FIGURE 27 - ABS Parts Identification Chart
