Road side top view road side top view – Bendix Commercial Vehicle Systems A-18 TRAILER ABS 5/04 User Manual
Page 18
18
Gladhand
Gladhand
TEV or STEV
Spring Brake
Control
Res.
Res.
Emergency
Brake
Chamber
Service
Brake
Chamber
ABS
ECU
3/4" Heavy Wall
Steel Pipe Nipple
Supply Line
Service (Control) Line
Front
ABS
Relay
Valve
3/8" O. D. Nylon Tubing
3/8" O. D. Nylon Tubing (Alt. 1/2" O. D.)
3/8" I. D. Hose
Key
Road Side
Top View
Road Side
Top View
ECU
Side
Wheel
Side
Power Cable
2S-1M Electrical Configuration (Top View)
J560 Connector
Trailer
Side
Warning
Light Side
Harness Side
ECU Side
Warning Lamp Connector
ABS Warning Lamp
ECU
Modulator
Valve
Diagnostic Port
Wheel Sensor
Speed Sensor
Sensor B
Sensor A
Front
ABS
2S-1M Air System Configuration (Top View)
(Shown with
Extension)
Description
Quantity
ECU/Relay Valve
1
Sensor/Diagnostics Cable
1
Valve/Power Cable
1
Sensors — 0.4m Cable
2
Sensor Friction Sleeve
2
Parts List
FIGURE 23 - Typical 2S-1M ABS Electrical and Air System
