PAGE 19 TP10320A
DESCRIPTION:DESCRIPTION:DESCRIPTION:DESCRIPTION:DESCRIPTION: UNIT NAME:UNIT NAME:UNIT NAME:UNIT NAME:UNIT NAME:
REV:REV:REV:REV:REV:
ASSEMBLY NUMBER:ASSEMBLY NUMBER:ASSEMBLY NUMBER:ASSEMBLY NUMBER:ASSEMBLY NUMBER:
SHEET OFSHEET OFSHEET OFSHEET OFSHEET OF
267-861-BG-01
ITEM NO. DESCRIPTION PART NO. QTY.
1 PJ604-06 MOUNTING BRACKET 268-096-01-00 1
2 PJ604-42 INJECTOR SUPPORT ARM 268-097-01-00 1
3 PJ604-07 FLUID CONTAINER SUPPORT 268-098-01-00 1
4 PJ604-10 NEEDLE VALVE 268-099-01-00 5
5 PJ604-30 STRAIGHT TUBE FITTING 268-100-01-00 1
6 PJ604-09 MANIFOLD 268-101-01-00 1
7 PJ604-11 MANIFOLD BRACKET 268-102-01-00 1
8 PJ604-12 SENSOR AMP. MOUNTING BRACKET 268-103-01-00 1
9 PJ604-17 SENSOR AMP. MODULE 268-104-01-00 1
10 PJ604-26 MALE 3 POLE RECEPTACLE 268-105-01-00 1
11 PJ604-28 FUSE 268-106-01-00 1
12 PJ604-24 FUSE HOLDER 268-107-01-00 1
13 PJ604-22 T & B CABLE STRAIN RELEIF 268-108-01-00 2
14 PJ604-23 ROCKER SWITCH 268-109-01-00 1
15 PJ604-21 ELECTRIC PLUG 268-110-01-00 1
16 PJ604-08 SOLENOID VALVE 268-111-01-00 1
17 PJ604-33 1/8 NPT STREET ELBOW 268-112-01-00 1
18 PJ604-37 VALVE MTG. BRACKET 268-113-01-00 1
19 PJ604-32 VINYL TUBING 10 in. Lg. 268-114-01-00 1
20 PJ604-27 QUICK DISCONNECT 268-115-01-00 1
21 PJ604-32 VINYL TUBING 24 in. Lg. 268-116-01-00 1
22 PJ604-13 CONTAINER SUPPORT 268-117-01-00 1
23 PJ604-15 CONTAINER RETAINER 268-118-01-00 2
24 PJ604-14 CONTAINER RETAINER 268-119-01-00 1
25 PJ604-20 POLYETHYLENE BOTTLE 268-120-01-00 1
26 PJ604-31 BULKHEAD FITTING 268-121-01-00 2
27 PJ604-40 SEAL WASHER 268-122-01-00 2
28 PJ604-03 SENSOR MOUNTING BLOCK 268-123-01-00 1
29 PJ604-04 SENSOR MOUNTING BAR 268-124-01-00 1
30 PJ604-16 NYLON THUMB SCREW 268-125-01-00 9
31 PJ604-25 3 POLE 90ß CONNECTOR 268-126-01-00 1
32 PJ604-02-1 NOOZLE HOLDER 268-127-01-00 1
33 PJ604-02-2 NOOZLE HOLDER 268-128-01-00 1
34 PJ604-02-3 NOOZLE HOLDER 268-129-01-00 1
35 PJ604-02-4 NOOZLE HOLDER 268-130-01-00 1
36 PJ604-32 VINYL TUBING 9 in. Lg. 268-131-01-00 1
37 PJ604-01 PIPE TO LEUR THREAD ADAPTER 268-132-01-00 4
38 PJ604-29 90ß ELBOW 268-133-01-00 4
39 PJ604-18 LEUR ADAPTER 268-134-01-00 4
40 PJ604-41 FIBER WASHER 268-135-01-00 4
41 PJ604-32 VINYL TUBING 60 in. Lg. 268-136-01-00 4
42 PJ604-19 HYPODERMIC NEEDLE 268-137-01-00 4
43 TYPE SJ 16/3 ELECTRIC CABLE 2 ft. Lg. 268-138-01-00 1
44 TYPE SJ 16/3 ELECTRIC CABLE 10 ft. Lg. 268-139-01-00 1
267-861-BG-01267-861-BG-01267-861-BG-01267-861-BG-01267-861-BG-01
WETSCORE ASSEMBLYWETSCORE ASSEMBLYWETSCORE ASSEMBLYWETSCORE ASSEMBLYWETSCORE ASSEMBLY
2
2
2
2
2
2
2
2
2
2
WETSCOREWETSCOREWETSCOREWETSCOREWETSCORE
