TP10320A
PAGE 16
0.625 in.
7.750 in.
0.750 in.
Drill & Tap for
M6 x 1.00
2 Plcs.
OPERATOR'S SIDE
(inside frame view, not to scale)
0.500 in.
3.500 in.
1.500 in.
Drill & Tap for
M6 x 1.00
2 Plcs.
NON-OPERATOR'S SIDE
(inside frame view, not to scale)
1400 SERIES INSTALLATION INSTRUCTIONS
