Atomos Ninja Star – User Manual Edition 1: October 2014 18
Ninja Star tech specs
NINJA STAR SPECIFICATIONS
Weight
Without batteries & HDD 130g/4.6oz
With batteries & HDD 230g/8.1oz
Dimensions (W x H x D mm) 95 x 60 x 25mm
Construction Advanced rubberised paint
Power
Operating power 3.5W / 4.5W (Rec,Play)
Compatible batteries
NP series, D-Tap and supporting accessories
(Nikon ENL6, Canon EL6)
Input voltage (battery) 6.2V to 16.8V
Battery time (based on 7.4V) 2600mAh - up to 5hrs
5200mAh - up to 9hrs
7800mAh - up to 14hrs
Continuous power
* Patent pending
via optional Power station
Powerstation continuous power dual
supply
Optional
Video input/loop out
HDMI 1 x HDMI Micro (1.4)
Signal Uncompressed 10/8bit 4:2:2
Video output (play out)
HDMI 1 x HDMI Micro (1.4)
Signal Uncompressed 10/8bit 4:2:2
Supported formats (in/out)
HD
1080i60, 1080i59.94, 1080i50, 1080p30,
1080p25, 1080p24, 1080p23.98, 1080pSF23.98,
1080pSF24, 1080pSF25, 1080pSF30,
SD 720p60, 720p59.94, 720p50, SD 480i, 576i
NINJA STAR SPECIFICATIONS
Realtime hardware encoding
1920x1080 8/10-bit 4:2:2 & SD to
Apple
HQ
422
LT
Onboard processing
25pSF > 25P (2:2 Pulldown)
30pSF > 30P (2:2 Pulldown)
60i > 24P (3:2 Pulldown)
59.94i > 23.98P (3:2 Pulldown)
Audio input (48kHz PCM audio)
Analog Line 2ch 48KHz (no gain control)
HDMI 2ch 48kHz
Audio output (48kHz PCM audio)
Analog line / Headphone 2ch 48kHz
HDMI 2ch 48kHz
Remote start/stop
HDMI
Auto HDMI Trigger
Supported Protocols - Canon, Sony, Atomos Open
Standard
Recording
Supported media
(Approved List Only)
Atomos CFast
Dock USB 2.0/3.0 CFast card reader
Supported applications
Supported Applications FCPX/FCP7+ / Media
Composer 5.0+ / Premiere 5.5+
EDIUS 6.0+ / Vegas Pro 10+ / Lightworks /
Autodesk Smoke 2015
Accessories included
Main unit, Universal battery charger 110-240V,
AC adapter & car charger, CFast card reader, 1
x Atomos 2600mAh battery, Rugged carry case,
Cheese plate mounting adapter
Optional extras
D-Tap adapter, Canon & Nikon adapter plates,
Connect H2S converter, Connect S2H converter,
CFast cards, Atomos specialty HDMI cables
Construction note:
Your Ninja Star is designed to operate in ambient temperatures up to
40°C/105°F. It features a fanless design which dissipates internal heat
through the aluminium chassis.
The top and bottom aluminium surfaces next to the tripod screws are the
heat sinks. Under warm or extended operating conditions, these surfaces
may get hot to the touch. This is normal part of the design, and shows that
your Ninja Star is dissipating heat successfully.
Have you registered your Ninja Star yet?
Register now to receive communication on all future updates
