BATTERIES

Two (2) Type AAA alkaline 1.5 V batteries are required to operate the Bushnell® Holosight® XLP. The

Bushnell® Holosight® XLP is designed to maintain constant brightness at a particular setting even as the

batteries drain through normal use. The reticle brightness will not fade gradually as the batteries drain,

but will shut down abruptly. The fi rst indication of the batteries draining is the reticle image blinking

when the unit is turned on (see Electronic Features Section). Another indication of low batteries is the

reticle image blinking off and on during recoil. With high recoil guns, this can occur before the battery

check indicates low battery condition. If the reticle image blinks during recoil or turns off suddenly,

replace the batteries. Read and follow the battery replacement and battery check procedures described

in this Manual. Alkaline batteries are constructed differently by manufacturers. Tests show some brands

are more susceptible to degradation by the shock of recoil. The use of Eveready Energizer® batteries with

the Bushnell® Holosight® XLP is recommended.

INSTALLING OR REPLACING BATTERIES

To remove the battery compartment

cover, rotate the battery cover knurled

screw counterclockwise and carefully

pull the cover away from the sight

housing (Figure 2). After the battery

cover is removed, slide the batteries out

and replace them with a fresh set. The

plus and minus signs next to the battery

insertion area indicates the correct

2

FIGURE 1

3

FIGURE 2
