INTRODUCTION
The Bushnell® Holosight® XLP is based on advanced holographic technology. The Bushnell®
Holosight® XLP enhances target acquisition, improves accuracy, and provides a high level of control
within the shooting environment. This user manual describes the features of the Bushnell® Holosight®
XLP and provides information on its use and maintenance. Please read the instructions carefully before
mounting and using the sight and always practice proper firearm safety.
Included:
• Assembled Holographic Diffraction Sight including mounting hardware
• 7/64” hex wrench (Weaver Base mount)
• 1/8” hex wrench (12 gauge model 1100, 870 or 1187 Remington® or similar)
BASIC OPERATION
The Bushnell® Holosight® XLP uses a laser to create an illuminated hologram in the display window
which appears as a virtual image of a reticle pattern. The reticle pattern appears to the user as a bright
red image which is projected onto the target plane. No laser light is projected onto the target. Note that
the Bushnell® Holosight® XLP has no magnification properties. Refer to Figure 1 for the user control
or adjustment features locations. Refer to the MOUNTING section for installation instructions and
correct placement on the gun.
1
