Appendix A: Specifications
Video Formats
• 525i 29.97
• 525i23.98*
• 625i 25
• 720P 23.98*, 24 *, 25 *, 29.97*, 30 *, 50, 59.94, 60
• 1080i 25, 29.97, 30
• 1080PsF 23.98, 24, 25, 29.97, 30
• 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60
• 2Kx1080p 23.98, 24, 25
• 2Kx1080PsF 23.98, 24, 25
Software-dependent Formats:
* These formats are dependent on specific software functionality and are not normal 'over-the-
wire' formats.
720P 23.98, 24, 25, 29.97, 30
Video Input
• 3G/SD/HD SDI, SMPTE-259/292/296/424, 10-bits
• Single Link 4:2:2 or 4:4:4 (1 x 3G BNC)
• dual link HD 4:4:4, (2 x BNC)
• HDMI v1.3
• 1D LUT Support (Mac and PC)
Video Output Digital
• 3G/SD/HD SDI, SMPTE-259/292/296/424
• Single link 4:2:2 or 4:4:4 (1 x BNC)
• dual link HD 4:4:4, (2 x BNC)
• HDMI v1.4, 30/36 bits/pixel, RGB or YUV, 2.25Gbps
Video Output Analog
• Composite/S-Video (Y/C) (1 x BNC/2x BNC+adapter)
• NTSC, NTSCJ, PAL
• Component (3 x BNC)
• HD: YPbPr, RGB
• SD: YPbPr, RGB (component mode)
• SMPTE/EBU N10, Betacam 525 line, Betacam 525J, RGB
• 12-bit D/A, 8x oversampling
• +/- .2 dB to 5.0 MHz Y Frequency Response
• +/- .2 dB to 1 MHz C Frequency Response
• .5% 2T pulse response
• <1% Diff Phase
