10
Specifications
Item Specification
Inputs SMPTE-259/292/296 SDI/HD-SDI
Input Formats 1080i, 1080p, 720p, 525i, 625i
Video Input HD-SDI/SDI, SMPTE-259/292/296/274
Outputs DVI-D (E-DDC and E-EDID compatible)
Audio (2 channel RCA-style outputs) @ -10dBV nominal
2 Looping SDI outputs of the SDI inputs
Supported Output Displays
(native resolution)
Note: for resolutions not listed
here, the HDP defaults to
1024 x 768
800 x 600 — SVGA
848 x 480 — Plasma
852 x 480 — Plasma
1024 x 600 — WSVGA
1024 x 768 — XGA
1280 x 720 — HDTV (720p)
1280 x 768 — WXGA
1280 x 960 — 4:3 SXGA
1280 x 1024 — SXGA
1360 x 768 — Plasma
1366 x 768 — Plasma
1400 x 1050 — Projector
1600 x 1024 — WSXGA
1600 x 1200 — UXGA
1680 x 1050 — Apple 20” Cinema HD
1920 x 1080 — HDTV (1080p)
1920 x 1200 — WUXGA
Maximum DVI resolution 1920 x 1200 @ 60Hz
Size 5.8” x 2.4” x 1” (131 x 61 x 25mm)
Power
(AJA power supply model DWP or
DWP-U) +5 to +18v DC regulated, 5 watts
