7 AJA D5CE Serial Digital Encoder User Manual — Installation
Installation
Typically, D5CE installation consists of the following:
1. disconnect +5VDC from the convertor
2. configure the DIP switch for the desired equipment configuration and video formats
3. connect video equipment to the convertor BNCs
4. apply +5VDC power to the converter (AJA power supply model DWP)
Specifications
Item Specification
Serial Input SMPTE 259M 270MB, (SDI)
SDI Cable Equalization 300 meter 8281 typical
Serial Output (looping) Equalized, Re-clocked
Outputs 1. YPbPr - SMPTE, EBU-N10, Betacam, RGB (3 BNCs)
2. NTSC, PAL (3 BNCs)
3. NTSC/PAL and Y/C (3 BNCs)
Frequency Response +/-.25dbto 5.5Mhz (Y)
+/-.25dbto2.0Mhz (Chroma-Component, RGB)
+/-.25dbto 1.3Mhz (Chroma - Composite)
2T K factor < 1% (Y)
Differential Gain < 1 .5%
Differential Phase < 1 .5 degree
Y/C delay 10ns maximum
D/A Converters 10 bits
Signal Path 8 bits
Delay (input to output) 1.5us
Output level adjustment +/- 20% (internal)
Output level matching 1 .5% or 10mv (All outputs are separately buffered)
Power
(AJA power supply model DWP) 5v DC regulated, 2.5 watt
Size 5.1" x 2.4" x 1" (131 x 61 x 25 MM.)
