Bank 0 Functions
FUNCTION DESCRIPTION DETAILS
0 BANK SEL Toggle UP/LEFT to select BANK 1
Toggle DOWN/RIGHT to select BANK 0 (Default)
1 INPUT MODE Toggle to cycle through these selections:
Auto Select (Default).
Currently, AUTO SELECT is the
only selection.
2 VERTICAL BLANK UP/LEFT = Blank Vertical Interval
DOWN/RIGHT = Pass Vertical Interval (Default)
Currently, Pass Vertical Interval (narrow blanking) is the
only selection
3 SETUP/PEDESTAL
REMOVEL UP/LEFT = No Pedestal on Input Video
DOWN/RIGHT = Input Pedestal Present (Default)
Functions only IN NTSC
4 COMPONENT/
COMPOSITE UP/LEFT = Component Input (Default)
DOWN/RIGHT = Composite Input
5 RGB/YPbPr/YC UP/LEFT = YPbPr if Component selected above or YC
if Composite selected above
DOWN/RIGHT = RGB if Component selected above or
Composite if Composite selected above
6 COMPONENT LEVELS UP/LEFT = SMPTE/EBU-N10 Levels (Default)
DOWN/RIGHT = Betacam 525/60 Levels
7 AGC UP/LEFT = Automatic Gain Control ON
DOWN/RIGHT = Automatic Gain Control OFF (Default)
8 CLEAR EEPROM and
RESET Toggle either way to clear EEprom contents, then
resets
9 RESET Toggle either way to reset
A COMB FILTER UP/LEFT = Comb OFF
DOWN/RIGHT = Comb ON (Default)
B COMB TYPE UP/LEFT = Adaptive 3 line Comb
DOWN/RIGHT = Adaptive 4 line Comb (Default)
C EDH UP/LEFT = EDH OFF
DOWN/RIGHT = EDH ON (Default)
D TEST PATTERN UP/LEFT = Pass Input (Normal Operation) (Default)
DOWN/RIGHT = Output Internal Test Pattern
E STORE/RECALL
USER SETUP Toggle UP/LEFT to Store Register
Toggle DOWN/RIGHT to Recall Register
F RESTORE DEFAULTS Toggle UP/DOWN to Restore Default Settings
