8
Installation
Typically, HD10AVA installation consists of the following:
1. configure the DIP switch for the desired equipment configuration and video/
audio formats—power to the converter may be on or off when this is done
(the converter will respond to DIP switch changes at the time they are made so
power cycling is not necessary)
2. ensure video/audio equipment is properly connected to the converter—check
all converter BNC and XLR connections
3. ensure the converter has a proper power supply source: +5 to +18VDC power
(we recommend AJA power supply model DWP)
Specifications
Item Specification
Formats 1080i 50/59.94/60 Hz
1080psf 23.98/24 Hz
1035i 50/59.94/60 Hz
720p 50/59.94/60 Hz
Video Inputs HD component YPbPr, (SMPTE-274), 3 BNC
SD component/composite/YC (S Video), 3 BNC
Video Outputs SDI, HD-SDI, SMPTE-259/292/296, 3 BNC
Audio Inputs 4 Channel Balanced, 4 XLR
Video A/D 12 bits
Audio A/D 24 Bits, 48Khz
Audio levels +12dBu, +15dBu, +18dBu, +24dBu, Full Scale Digital
User Controls External Dipswitch:
Component/Composite (SD)
Composite/YC (SD)
Pedestal Present (on/off) (SD)
Audio Input Level
Embed Audio on/off
Size 5.8" x 3.1" x 1 (147 x 79 x 25mm)
Power 5-18V, 5 watts. Requires power supply.
