AJA HD10AVA User Manual
Page 7
1
7
AJA HD10AVA Converter
Input Level Selection Matrix For Switches 4 and 5
The following table shows the combinations of DIP switch settings required to
configure the audio input levels shown.
Switch 6 (AUDIO EMBED)—Turns SDI audio embedding ON or OFF.
Switch 7 (AUX)—Switches Input Levels to NTSC-J
:
Switch 8 (AUX)—Controls Wide/Narrow blanking for SD formats; it
does not apply to HD formats
The operation of switch 8 is independent of all other switches. It affects the output of
SD video during vertical blanking lines.
:
Input Level Range
Full Scale
(0dBFS)
DIP Switch
#4
DIP Switch
#5
Professional US
+24dBu
LEFT
LEFT
Professional European
+18dBu
LEFT
RIGHT
Consumer High (IHF)
+12dBu
RIGHT
LEFT
Consumer Low
+15dBu
RIGHT
RIGHT
LEFT (ON)
RIGHT (OFF)
ON converts and embeds the
input audio into the digital SDI
outputs
OFF turns audio embedding off;
input audio is not supplied with the
SDI outputs.
LEFT (OFF)
RIGHT (ON)
Normal operation (NTSC levels)
NTSC-J levels for Composite, S-
Video, and BETA inputs
LEFT (OFF)
RIGHT (ON)
All data during vertical blanking
is replaced with black (Y =
0x40, C = 0x200)
Only active lines are digitized.
If input video is NTSC, HD10AVA
also digitizes the luminance data
present on lines 10-20 and lines
272-283, in addition to normal active
video lines.
If input video is PAL, HD10AVA also
digitizes the luminance data present
on lines 6-22 and lines 318-335 in
addition to normal active video lines.
