Glued or curled documents may cause a paper jam or damage in the ADF unit.
The height of the documents placed in the feeder tray must not exceed the paper limit mark that
appears on the right side of the document guide. (
See the diagram on page 57.
)
The following chart indicates the maximum number of sheets that can be loaded on the feeder tray:
Sheets that are exceptionally thick or thin should be placed in the ADF manually, one sheet at a time.
Curled, wrinkled, or folded documents may not scan properly. Check the allowances for curl and fold
in the following diagram:
Paper weight (pounds)
11
14
17
20
21
24
28
34
Paper weight (grams/meter
2
)
40
52
64
75
80
90
104
127
Maximum number of sheets
320
260
200
170
160
140
120
100
Curl must be
less than 0.20
inches (5 mm)
Fold must be
less than 0.20
inches (5 mm)
Feeding direction
Feeding direction
